Double color lens mold for car head lighting, UV coating, mold steel NAK80/1.2343ESU. Mold rotates 180°. Accurate parting surface and sealing surface are required for the smooth joint.
High glossy bezel mold, PC black+PC clear, texture on A surface, hot runner system with side gate. Cavities 2LH+2RH, mold size 1,620*1,170*860mm, two barrels injection machine 1,200T.
High-mount stop lamp lens with material PMMA black+PMMA red. Mold steel 1.2343ESR, HRS hot runner valve gate, 2LH+2RH, mirror polish, mold life 500,000 shots.
Double-color bezel mold for Project F537 high positioned rear brake light, milky white and black, 2LH+2RH. Mold steel 1.2343/NAK80, fully automatic running.
Multi-color lens mold for tail light, 2LH+2RH. 1st shot for outer red and transparent PMMA; 2nd shot for inner red PMMA. Mold size 1,710*1,180*1,202mm, press machine 1,300T.
Trunk side of taillamp lens includes three colors, PMMA clear, red and black. Part weight 245g. Mold steel 1.2343ESR, mold dimension 1,380*950*892mm.
